Double Leaf Fire Door
A double leaf fire door for main fire exits, lobby access points and equipment passage where a single leaf is too narrow. Equal or unequal leaves up to 2,100mm wide, with an EN 1158 door coordinator ensuring correct closing sequence, rated to 60, 90 or 120 minutes.
| Width | up to 2,100mm |
| Rating | 60/90/120 min |
| Brand | Yadav Entrance Automation Pvt. Ltd. |
| Manufacturing | Made in India · ISO 9001 · CE |
Which Fire Rating Do You Need?
Fire rating specifies how long a door assembly can resist fire without structural failure, flame passage, or excessive heat transmission. NBC 2016 mandates specific ratings for each building use type.
Not sure which rating applies to your building? Our fire safety consultants will advise free of charge →
ISO 9001 · CE marked · Make-in-India · Manufacturing since 2011 · 500+ installations across 50+ cities. See the full Fire Door range and how we build it, or read more about our plant and capabilities.
Double Leaf Fire Door: Technical Specifications
Complete engineering data for our fire rated door range. Specifications cover the standard steel fire door with panic bar hardware. Aluminium and acoustic variants differ in door leaf construction.
| Parameter | Specification |
|---|---|
| Fire Rating Options | 60 / 90 / 120 / 180 minutes: third-party tested per EN 1634 / IS 3614 |
| Door Leaf Material | GI sheet (24 gauge outer) / MS sheet with fire-rated core fill |
| Core Infill | Rockwool mineral wool (60/90/120 min) / Calcium silicate board (180 min) |
| Door Leaf Thickness | 45mm (60 min) / 50mm (90 min) / 60mm (120/180 min) |
| Frame Type | Steel sub-frame (2mm pressed steel) with fire-rated intumescent grout fill |
| Frame Fixing | M12 anchor bolts at 300mm centres; fully welded mitre joints |
| Panic Bar Hardware | EN 1125 certified touch bar / push bar: opens with single downward push |
| Door Closer | EN 1154 certified overhead hydraulic closer: Size 2–7 adjustable |
| Lever Handle | EN 179 certified lever handle (non-panic doors) |
| Smoke Seal | Intumescent strip (expands at 150°C) + EPDM brush seal: all four edges |
| Hinge Type | 3 × EN 1935 Gr.14 CE-marked stainless steel hinges per leaf |
| Glazing Option | Fire-rated Georgian wired glass or ceramic glass (up to 30% of leaf area) |
| Maximum Single Leaf Size | 1,100mm wide × 2,400mm high |
| Maximum Double Leaf Size | 2,100mm wide × 2,400mm high (equal or unequal leaves) |
| Sidelight Option | Up to 500mm wide fixed sidelights with fire-rated glass available |
| Acoustic Rating (Soundproof Variant) | Up to 42 Rw dB (weighted sound reduction index) |
| Finish Options | Powder coat (standard) / hot-dip galvanized / SS304 cladding |
| Operating Temperature | -10°C to +50°C ambient (door hardware rated) |
| Standards | IS 3614, EN 1634-1, UL 10C (positive pressure), NBC 2016 |
| Hardware Standards | EN 1125 (panic), EN 1154 (closer), EN 179 (handle), EN 1935 (hinges) |
| Warranty | 5 years structural, lifetime door frame, 2 years hardware |
What the Double Leaf Fire Door is, and who it suits
The Double Leaf Fire Door is a type of fire rated doors used across warehouses, factories, cold stores and commercial buildings. It is built to order at our Neemrana plant, installed and commissioned by our own engineers, and supported afterwards with spares and maintenance. See the full Fire Rated Doors range, the sectors we serve, or every product line.
- Warehouse and distribution-centre openings
- Factory and production-floor entrances
- Cold stores and temperature-controlled rooms
- Clean rooms and pharmaceutical areas
- Loading bays and dispatch docks
- Commercial building entrances
- Clear opening width and height (the daylight opening, not the wall opening)
- Lintel / headroom above the opening
- Side-room free each side for guides and motor
- Power available at the opening: 230V single-phase or 415V three-phase, 50 Hz
- Approximate cycles per day
- Any fire-rating, temperature or hygiene requirement
Send these with your enquiry and an engineer replies with a drawing and a written delivery date, rather than a generic response. Talk to an engineer →
Reference: manufacturing certified to ISO 9001, applicable products CE marked (European Commission), built to Indian Standards published by the Bureau of Indian Standards.
Double Leaf Fire Door: Engineered & Supported Across India
The Double Leaf Fire Door is manufactured and supported entirely within India. As an Indian manufacturer of fire rated doors, Yadav Entrance Automation Pvt. Ltd. engineers each unit for the realities of Indian warehouses, factories, cold stores and commercial buildings, variable power supply, high ambient temperatures, dust and monsoon humidity, and backs it with in-house manufacturing, pan-India installation and after-sales maintenance.
- Made in IndiaManufactured in-house at our Indian facilities: qualifies as a Make-in-India product for government and PSU procurement.
- Standard Indian MainsPowered models run on 230V single-phase or 415V three-phase at 50 Hz; manual / non-powered options where applicable.
- Established Since 2011Part of a track record of 500+ installations across 50+ Indian cities.
- Pan-India Install & AMCInstallation, genuine spare parts and Annual Maintenance Contracts (AMC) available nationwide.
- GST-Compliant SupplyGST invoicing for Indian businesses, with documentation suited to enterprise and PSU procurement.
- Built for Indian ConditionsSpecified for the heat, dust and monsoon humidity common on Indian industrial sites.
Strong on-ground presence in the NCR & Haryana industrial corridor, Gurugram, Manesar, Bhiwadi, Neemrana, Bawal, Faridabad, Noida, Jhajjar, Bahadurgarh and Delhi, and the Gujarat industrial belt, Ahmedabad, Sanand, Vithlapur and Mandal. Installation and service available across India. See all areas we serve →
Where the Double Leaf Fire Door fits
Wide rated openings, up to 2,100mm, where a single leaf would be too heavy to swing comfortably or too wide for the space available: corridors carrying trolleys, plant room entries, goods routes between compartments, and escape routes sized for larger occupancies.
Double Leaf Fire Door vs the alternatives
Against the single-leaf steel door, the width is the reason to choose it, and the cost is complexity. Two leaves need a meeting stile, coordinated closing so they shut in the right order, and rated seals at the joint as well as the perimeter. It is a well-understood arrangement, but it is more to get right and more to maintain.
Specifying a Double Leaf Fire Door
Give the clear opening width you actually need, not the structural one, since the meeting stile takes some of it. Tell us whether both leaves are used routinely or one is normally bolted shut, and confirm the rating and swing direction from the fire strategy. Say what has to pass through, because trolley and pallet widths often drive the decision.
Double Leaf Fire Door: Frequently Asked Questions
How wide can a double-leaf fire door be?
Do both leaves need to close in a set order?
Can one leaf be kept bolted shut?
Is the joint between leaves as fire-resistant as the leaves?
Does a double-leaf door need two closers?
Which regions do you install and service in?
Do you provide installation, spares and AMC?
Is the Double Leaf Fire Door certified?
Every Fire Door Quote Includes Test Certificates
When you request a fire door quote from Yadav Entrance Automation, you receive a specification document listing the exact fire rating, test certificate references, and hardware standards, ready to submit to your fire consultant or building plan approvals office.
Third-Party Test Certificates Provided
We provide CBRI / NABL-accredited test report references for every fire rating we supply. No self-declarations.
Fire NOC Documentation Support
Our compliance team assists with fire NOC submission documentation, drawing packages, and technical data sheets required by local fire departments.
Annual Inspection & AMC Available
Fire doors require annual maintenance inspection per NBC 2016. Our AMC includes closer calibration, seal inspection, and a compliance certificate.
