Polycarbonate / Transparent Rolling Shutter
A polycarbonate transparent rolling shutter combining aluminium frames with clear PVC or polycarbonate vision panels. Lets shopfronts display merchandise while closed, with full security and weather sealing.
| Panel | clear PC / PVC |
| Best for | showrooms |
| Brand | Yadav Entrance Automation Pvt. Ltd. |
| Manufacturing | Made in India · ISO 9001 · CE |
ISO 9001 · CE marked · Make-in-India · Manufacturing since 2011 · 500+ installations across 50+ cities. See the full Rolling Shutter range and how we build it, or read more about our plant and capabilities.
Polycarbonate / Transparent Rolling Shutter: Technical Specifications
Complete engineering data for the rolling shutter range. Specifications listed are for standard Motorized Aluminium, other variants differ in material and drive parameters.
| Parameter | Specification |
|---|---|
| Lath Profile Height | 77mm standard / 92mm heavy-duty |
| Lath Thickness: Steel | 0.8mm (economy) / 1.2mm (standard) / 1.6mm (heavy) |
| Lath Thickness: Aluminium | 1.2mm (standard) / 1.5mm / 2.0mm (heavy) |
| Maximum Single Width | 10,000 mm (single curtain, no intermediate post) |
| Maximum Width (Multi-Curtain) | 18,000 mm (with flush intermediate guide post) |
| Maximum Height | 8,000 mm |
| Drive: Manual | Gear handle (single gear) or push-up (light duty) |
| Drive: Electric | Single-phase 230V or three-phase 415V tubular motor |
| Motor Power Range | 0.25 kW (up to 3m × 3m) to 2.2 kW (large bays) |
| Operating Speed: Motorized | 6–10 m/min (adjustable via limit switches) |
| Daily Cycle Rating | 20–50 cycles per day (standard); 50+ cycles heavy duty |
| Control Options | Push button (standard) / RF remote / Loop detector / Timer / GSM |
| Wind Load: Standard | 55 km/h (MS standard) / 80 km/h (aluminium) / 100 km/h (reinforced) |
| Bottom Beam | Extruded aluminium with EPDM sealing strip; galvanized steel option |
| Side Guide Channels | 1.5mm / 2mm / 3mm rolled steel or aluminium |
| Finish: Steel | Hot-dip galvanized (85 micron) or powder coat (60–80 micron) |
| Finish: Aluminium | Mill finish / anodized (20 micron) / powder coat (custom RAL) |
| Spring Counterbalance | Pre-tensioned torsion spring; Helical spring on manual large bays |
| Drum Barrel | 76mm dia. (light) / 102mm dia. (standard) / 152mm dia. (heavy) |
| Shaft | Solid 25mm / 32mm / 50mm hex steel shaft depending on size |
| IP Rating: Motor | IP44 standard / IP55 optional (outdoor / washdown) |
| Certifications | ISO 9001:2015; BIS Mark (selected MS models); IS 6248 compliant |
| Warranty | 2 years motor, 3 years structure, 1 year surface finish |
What the Polycarbonate / Transparent Rolling Shutter is, and who it suits
The Polycarbonate / Transparent Rolling Shutter is a type of rolling shutters used across warehouses, factories, cold stores and commercial buildings. It is built to order at our Neemrana plant, installed and commissioned by our own engineers, and supported afterwards with spares and maintenance. See the full Rolling Shutters range, the sectors we serve, or every product line.
- Warehouse and distribution-centre openings
- Factory and production-floor entrances
- Cold stores and temperature-controlled rooms
- Clean rooms and pharmaceutical areas
- Loading bays and dispatch docks
- Commercial building entrances
- Clear opening width and height (the daylight opening, not the wall opening)
- Lintel / headroom above the opening
- Side-room free each side for guides and motor
- Power available at the opening: 230V single-phase or 415V three-phase, 50 Hz
- Approximate cycles per day
- Any fire-rating, temperature or hygiene requirement
Send these with your enquiry and an engineer replies with a drawing and a written delivery date, rather than a generic response. Talk to an engineer →
Reference: manufacturing certified to ISO 9001, applicable products CE marked (European Commission), built to Indian Standards published by the Bureau of Indian Standards.
Polycarbonate / Transparent Rolling Shutter: Engineered & Supported Across India
The Polycarbonate / Transparent Rolling Shutter is manufactured and supported entirely within India. As an Indian manufacturer of rolling shutters, Yadav Entrance Automation Pvt. Ltd. engineers each unit for the realities of Indian warehouses, factories, cold stores and commercial buildings, variable power supply, high ambient temperatures, dust and monsoon humidity, and backs it with in-house manufacturing, pan-India installation and after-sales maintenance.
- Made in IndiaManufactured in-house at our Indian facilities: qualifies as a Make-in-India product for government and PSU procurement.
- Standard Indian MainsPowered models run on 230V single-phase or 415V three-phase at 50 Hz; manual / non-powered options where applicable.
- Established Since 2011Part of a track record of 500+ installations across 50+ Indian cities.
- Pan-India Install & AMCInstallation, genuine spare parts and Annual Maintenance Contracts (AMC) available nationwide.
- GST-Compliant SupplyGST invoicing for Indian businesses, with documentation suited to enterprise and PSU procurement.
- Built for Indian ConditionsSpecified for the heat, dust and monsoon humidity common on Indian industrial sites.
Strong on-ground presence in the NCR & Haryana industrial corridor, Gurugram, Manesar, Bhiwadi, Neemrana, Bawal, Faridabad, Noida, Jhajjar, Bahadurgarh and Delhi, and the Gujarat industrial belt, Ahmedabad, Sanand, Vithlapur and Mandal. Installation and service available across India. See all areas we serve →
Where the Polycarbonate / Transparent Rolling Shutter fits
This is a display-first shutter. It belongs on showroom and mall frontages where the merchandise behind the glass is doing the selling and should keep working after the shutters come down. Aluminium frames carry clear polycarbonate or PVC vision panels, so the opening is closed and secured while remaining genuinely see-through rather than merely perforated.
Polycarbonate / Transparent Rolling Shutter vs the alternatives
Against a perforated curtain, polycarbonate gives a clear view instead of a screened one, and it seals the opening rather than ventilating it. Against a solid shutter, the display value is incomparably better, but the vision panels are polymer rather than steel and will not take the same abuse. It is a shopfront and showroom product, not a product for a bay where vehicles pass.
Specifying a Polycarbonate / Transparent Rolling Shutter
Tell us how much of the curtain should be glazed and how much aluminium, since most installations are a mix rather than fully clear. Say how exposed the frontage is to direct sun, and how the panels will be cleaned and reached, because a curtain that cannot be cleaned stops looking like a display very quickly. Confirm the security expectation for the opening so the frame sections and locking are specified appropriately.
Polycarbonate / Transparent Rolling Shutter: Frequently Asked Questions
Do the clear panels scratch or discolour?
How should the panels be cleaned?
Is a polycarbonate shutter as secure as a solid one?
Can I have clear panels only in part of the curtain?
Is polycarbonate or PVC the better panel?
Which regions do you install and service in?
Do you provide installation, spares and AMC?
Is the Polycarbonate / Transparent Rolling Shutter certified?
Built Accurately to Your Opening
Manufactured in India: Zero Import Dependency
Our CNC roll-forming lines run all material grades in-house. No delays from import disruptions.
Free Measurement & Site Assessment
We send a technician to measure your openings and check structural suitability, free of charge anywhere in our service areas.
Turnkey Supply & Install: One Invoice
Material, motor, civil work, wiring, and commissioning all covered under a single project invoice. No sub-contractor surprises.
